<div layer1="text-s"></div><div class="tz-paragraph">自从换了副厂带电动调节的大灯以后，一直想加装一个电动调节开关，毕竟预留了安装位。首先买个开关，20块钱包邮的那种。</div><div layer1="text-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g27/M09/8F/16/userphotos/2021/12/03/14/500_ChwFkWGptCCABb8oAAfKFx1X4j8942.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">按这个角度，从左到右分别是3&nbsp;2&nbsp;1脚</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="text-s"></div><div class="tz-paragraph">插头就比较难办了，不好买，价格也高，就地取材</div><div layer1="text-e"></div><br /><div layer1="img-s"></div><div class="tz-picture"><img src="http://club2.autoimg.cn/album/g28/M09/79/D1/userphotos/2021/12/03/14/500_ChwFkmGptCOAVHYCAAGe3ghHn-s778.jpg" style="height:750px;width:750px"  /></div><div layer1="img-e"></div><br /><div layer1="text-s"></div><div class="tz-paragraph">这个都见过吧，壁纸刀裁掉一个针脚，其余3脚重新压线，2&nbsp;3脚30公分左右，1脚大约2米50左右，具体没量，起初短了自己又接了点。<br />接下来看看电路图</div><div layer1="text-e"></div><br /><div layer1="img-s"></div><div class="tz-picture"><img src="http://club2.autoimg.cn/album/g28/M0B/79/D2/userphotos/2021/12/03/14/500_ChwFkmGptCaACnIIAAdNhu30gvk576.jpg" style="height:1656px;width:1242px"  /></div><div layer1="img-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g28/M02/79/D2/userphotos/2021/12/03/14/500_ChwFkmGptCmAYNZwAAexcCR3P6s767.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">找到10v&nbsp;nr插头位置</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="text-s"></div><div class="tz-paragraph">开关的1脚接大灯的7脚，测量发现左右大灯的7脚是连通的，开关的2脚接10V&nbsp;NR的7脚，3脚随便接地。<br />难点就是接大灯插头的7脚，我找了很多资料也没找到从驾驶室哪里接，没办法只能接到发动机室接到大灯插头上。</div><div layer1="text-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g27/M04/6D/15/userphotos/2021/12/03/14/500_ChxkmWGptCqADAcKAAbh2Jd97kA598.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">从刹车左边这里的橡胶塞子进去</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g27/M0B/8F/17/userphotos/2021/12/03/14/500_ChwFkWGptCyAFYu2AAbIx56eqlo337.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">穿一根铁丝发现可以从电瓶后面引出来</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g28/M06/79/D2/userphotos/2021/12/03/14/500_ChwFkmGptC2AIgN8AAeW-oNdV94261.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">塞子上打个孔，或者用开孔器，厚度大约6mm左右</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="img-s"></div><div class="tz-picture"><img src="http://club2.autoimg.cn/album/g28/M02/79/D3/userphotos/2021/12/03/14/500_ChwFkmGptDGAWNrwAAdIHNB8Asc748.jpg" style="height:1656px;width:1242px"  /></div><div layer1="img-e"></div><br /><div layer1="text-s"></div><div class="tz-paragraph">接下来并线</div><div layer1="text-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g28/M0A/69/C5/userphotos/2021/12/03/14/500_ChxkmmGptDOAAwlvAActapgvF10574.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">破线上焊锡，然后胶布包上，做好防护</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g28/M0B/69/C5/userphotos/2021/12/03/14/500_ChxkmmGptDiACKkoAAevNBD5F1c618.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">这是大灯的7脚</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g27/M09/6D/16/userphotos/2021/12/03/14/500_ChxkmWGptDuAIlezAAcJlWtB-aM217.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">发动机位置用波纹管套上，然后从红线位置有线，并用扎带固定</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="img-s"></div><div class="tz-figure"><img src="http://club2.autoimg.cn/album/g27/M04/8F/17/userphotos/2021/12/03/14/500_ChwFkWGptD-ABUryAAdRr1Jmbok773.jpg" style="height:1656px;width:1242px"  /><div layer2="desc-s"></div><div class="deXss ion">最后整理一遍，打开近光试了一下，一共6个档位，0最高。</div><div layer2="desc-e"></div></div><div layer1="img-e"></div><br /><div layer1="text-s"></div><div class="tz-paragraph">到这里大灯水平调整开关就安装完毕。</div><div layer1="text-e"></div><br />

10款 307 1.6AT 加装大灯水平调整开关
